Boss GX-100

Description

Standard Features

• Powerful, easy-to-use amp/effects processor for guitar and bass
• 24-bit AD/DA, 32-bit floating-point processing, and 48 kHz sampling rate
• Authentic tube amplifier tone and touch response with AIRD technology
• 23 amplifier types and over 150 BOSS effects
• Ultra-flexible amp/effect routing with 15 assignable blocks
• Wide selection of onboard speaker types and support for loading WAV speaker IRs
• Streamlined modern design with intuitive color touch display and rugged metal chassis
• Unlimited effects control with freely assignable onboard footswitches and expression pedal with toe switch
• Connect up to two footswitches or an expression pedal for expanded control
• Send/return loop for external pedals or four-cable method
• Control jack for remote channel switching on your amplifier
• MIDI I/O jacks and multi-channel computer recording via USB
• Edit sounds from your computer with BOSS Tone Studio for macOS and Windows
• Optional Bluetooth® Audio MIDI Dual Adaptor allows you to edit sounds and stream audio from an iOS or Android mobile device

SPECIFICATIONSSampling Frequency48 kHzAD Conversion24 bits + AF method
AF method (Adaptive Focus method) This is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters.DA Conversion24 bitsProcessing32-bit floating pointEffects154 TypesMaximum Number of Effects15+3 (DIVIDER/MIXER, SEND/RETURN, PHRASE LOOP)
*depending on the circumstancesMemories200 (User) + 100 (Preset)Phrase Loop38 sec. (MONO)
19 sec. (STEREO)Tuner Internal Detection+/-0.1 centNominal Input LevelINPUT: -10 dBu
RETURN: -10 dBuMaximum Input LevelINPUT: +18 dBu
RETURN1: +8 dBuInput ImpedanceINPUT: 1 M ohm
RETURN: 1 M ohmNominal Output LevelOUTPUT (L/MONO, R): -10 dBu
PHONES: -10 dBu
SEND: -10 dBuOutput ImpedanceOUTPUT (L/MONO, R): 1 k ohm
PHONES: 44 ohms
SEND: 1 k ohmRecommended Load ImpedanceOUTPUT (L/MONO, R): 10 k ohms or greater
PHONES: 44 ohms or greater
SEND: 10 k ohms or greaterControlsBANK DOWN switch, BANK UP switch, CTL1 switch, CTL2/TUNER switch, 1–4 switches, POWER switch, EXP1 switch, GND LIFT switch

EFFECTS button, CTL/EXP button, MENU button, EXIT button, WRITE button, IN/OUT SETTINGS button, PAGE button,1–4 knobs

SELECT knob, OUTPUT LEVEL knob, EXP1 pedalDisplayColor Graphic LCD (480 x 272 dots) Touch screenConnectorsINPUT jack, OUTPUT (L/MONO, R) jacks, SEND jack, RETURN jack: 1/4-inch phone type
PHONES jack: Stereo 1/4-inch phone type
CTL3, 4/EXP2 jack, AMP CTL1, 2 jack: 1/4-inch TRS phone type
MIDI (IN, OUT) connectors
USB COMPUTER port: USB B type
Bluetooth ADAPTOR connector: Dedicated connector
DC IN jackPower SupplyAC adaptorCurrent Draw1.2 AAccessoriesAC adaptor (PSB-1U + AC Cord Set)
Owner’s manual
Leaflet “USING THE UNIT SAFELY”Options (sold separately)Footswitch: FS-5U, FS-5L, FS-6, FS-7
Expression Pedal: EV-30, FV-500L, FV-500H, Roland EV-5
Bluetooth(R) Audio MIDI Dual Adaptor: BT-DUAL
Carry Bag: CB-ME80SIZE AND WEIGHTWidth460 mm
18-1/8 inchesDepth193 mm
7-5/8 inchesHeight73 mm
2-7/8 inchesMaximum height94 mm
3-3/4 inchesWeight3.5 kg
7 lbs 12 oz
