SPEC
-
SPECS
- neck type
- GRGMaple neck
- top/back/body
- Poplar Burl Art Grain (Basswood) topOkoume body
- fretboard
- Bound Purpleheart fretboardReversed White Sharktooth inlay
- fret
- Medium frets
- number of frets
- 24
- bridge
- F106 bridge
- string space
- 10.5mm
- neck pickup
- IBZ-6 (H) neck pickupPassive/Ceramic
- bridge pickup
- IBZ-6 (H) bridge pickupPassive/Ceramic
- factory tuning
- 1E,2B,3G,4D,5A,6E
- string gauge
- .010/.013/.017/.026/.036/.046
- hardware color
- Black
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5″
- a : Width
- 43mm at NUT
- b : Width
- 58mm at 24F
- c : Thickness
- 19.5mm at 1F
- d : Thickness
- 21.5mm at 12F
- Radius :
- 400mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
SWITCHING SYSTEM
DESCRIPTION
When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is in between neck and center position, bridge side of the neck pickup is selected. When the switch is in center position, both neck and bridge pickup s are selected. When the switch is in between center and bridge position, the bridge side of the neck pickup and the bridge side of the bridge pickup are selected. When the switch is in bridge position, bridge pickup is selected.
-
CONTROLS
DESCRIPTION
-
OTHER FEATURES
-
| Weight | 12 lbs |
|---|---|
| Dimensions | 45 × 15 × 8 in |
