SPECS
- body shape
- Cutaway Dreadnought body
- top
- Spruce top
- back & sides
- Okoume back & Okoume sides
- neck
- PFNyatoh neck
- fretboard
- Laurel fretboard
- bridge
- Laurel bridge
- inlay
- White dot inlay
- soundhole rosette
- Black & White multi
- tuning machine
- Chrome Die-cast tuners
- number of frets
- 20
- bridge pins
- Ibanez Advantage™
- strings
- Ibanez IACS6C
- string gauge
- .012/.016/.024/.032/.042/.053
- string space
- 11mm
- factory tuning
- 1E,2B,3G,4D,5A,6E
- pickup
- Ibanez Undersaddle
- preamp
- Ibanez AEQ-2T preamp w/Onboard tuner
- output jack
- 1/4″ output
- battery
- 9V x1
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5″
- a : Width
- 42mm at NUT
- b : Width
- 54mm at 14F
- c : Thickness
- 21mm at 1F
- d : Thickness
- 22.5mm at 7F
- Radius :
- 240mmR
-
DESCRIPTION
-
-
BODY DIMENSIONS
-
- a : Length
- 20 1/8“
- b : Width
- 15 3/4“
- c : Max Depth
- 5“
-
DESCRIPTION
Guitar Body Diagram
A: Length of the body
B: Maximum width of the body
C: Maximum depth of the body
-
-
PREAMP
DESCRIPTION
The neck side of the preamp is the top of the control panel. There is one button and three knobs along the top of the control panel. The button furthest to the left is the tuner on/off switch. To the right of that are the bass, treble, and volume knobs.
-
OTHER FEATURES
