Amp Type
Tube
Rectifier Type
Silicon Diodes
Rectifier Tubes
n/a
Variac PowerSwitch
n/a
Preamp Tubes
5x Mesa 12AX7 & 1x Mesa 12AT7
Power Amp Tubes
4x Mesa 6V6
Maintenance Free Fixed Bias
n/a
Wattages Quick Reference
2, 10, 20, 30 or 40 Watts – See Power Amp Details for more information
Built In Power Amp Attenuation
n/a
Power Amp Details Class Wattage
Mesa’s Patented Incremental Multi-Watt™ (Patent 9,917,560) Power Amp, featuring Duo-Class™ (Patent 7,173,488) and Dyna-Watt technologies, provides five power, two operating-classes and three wiring configuration options via one 5-Way Power Switch – Choose from the following power options: 40 Watt – 4x6V6 Class A/B Pentode 30 Watts – 2x6V6 Class A/B Triode + 2x6V6 Class A/B Pentode 20 Watts – 2x6V6 Class A/B Pentode 10 Watts – 2x6V6 Class A/B Triode 2 Watts – 1x6V6 Triode + 1x6V6 Pentode, Single-Ended Class A Parallel More information on Dyna-Watt Power can be found in the Owners Manual, which is available in the Support Section of this website.
Number Of Style Modes
Two (Inputs)
Number Of Style Modes Per Channel
Two (Inputs)
Channel Controls
Gain, Treble, Mid, Bass, Presence, Reverb and Master
Graphic Eq And/or Contour
n/a
Reverb Effects Bypass Options
All-Tube, Spring Reverb
Effects Loop Bypass Options
Fully Buffered Series FX Loop
Global Output Level Control
n/a
Global Solo Level Control
n/a
True Bypass Options
n/a
External Switching Jack Options And/or Midi
External Switching Jack for Reverb On/Off (Reverb Footswitch and Cable sold seperately)
Speaker Outputs
One 8 Ohm and Two 4 Ohm
Cabinet Simulation Direct Live recording Output
n/a
Internal Amp Load For SpeakerLess Performance
n/a
Headphone Output
n/a
Slave Output
n/a
Extra Features
n/a
