Quick Overview |
|
|---|---|
| Build Location | Hand-Wired In Petaluma, CA with the World’s Finest Materials |
| Wattage | Multi-Watt™ 10 or 25 (Channel Assignable) |
| Power Tube Type | 2x Mesa EL84 |
| Channels & Modes | 2 Channels / 4 Modes |
| Mode Voicings / Styles | Ch. 1 = Clean or Pushed Ch. 2 = Vintage or Modern |
| Graphic EQ / Reverb / FX / Solo | Reverb, FX Loop |
| Footswitchable Functions | Ch. 1/2 |
| Speaker(s) & Impedance | 1 – 8 Ohm Celestion Vintage 30 / Total Load = 8 Ohms |
| Weight | 41 Lbs. |
| Dimensions | 17″ H x 19″ W x 11″ D |
| Available Formats | Head, Rackmount & 1×12 Combo |
Amplifier Features |
|
|---|---|
| Amp Type | Tube |
| Chassis Material | Aluminum |
| Rectifier Type | Silicon Diodes |
| Rectifier Tubes | n/a |
| Variac Power Switch | n/a |
| Preamp Tubes | 6x Mesa 12AX7 |
| Power Amp Tubes | 2x Mesa EL-84 |
| Bias Switch for Alternate Power Tubes Types | n/a |
| Maintenance Free Fixed Bias | Yes |
| Wattage(s) Quick Reference | 10 or 25 Watts – Channel Assignable – See Power Amp Details for more information |
| Built-In Power Amp Attenuation | n/a |
| Power Amp Details (Class & Wattage) | Mesa’s Patented Multi-Watt™ (Patent 7,602,927) Power Amp, featuring Dyna-Watt™ technology, providing two power levels, each with different wiring configurations (Pentode/Triode) via two 10/25 Watt Power Switches: Choose from 2 power tubes operating in Class A/B Triode for lush harmonics and a sweet, liquid feel at lower volumes, producing 10 Watts or; 2 tubes operating in Mesa’s proprietary Dyna-Watt™ Class A/B Pentode for maximum power, punch and clarity, producing 25 Watts |
| Convection or Fan Cooling | Convection |
| Number of Footswitchable Channels (or Modes) | Two Channels |
| Number of Style Modes | Four |
| Number of Style Modes Per Channel | Two |
| Types of Style Modes Per Channel | Ch. 1 = Clean or Pushed Ch. 2 = Vintage or Modern |
| Channel Controls | Each Channel features Independent 2-Position Style Mode Switch, 10/25 Watt Multi-Watt™ Switch, Gain, Treble, Mid, Bass, Presence, Reverb (back panel) and Master Control |
| Graphic EQ and/or Contour | n/a |
| Reverb / Effects & Bypass Options | All-Tube, Long Spring Reverb with Independent Channel Controls (back panel) |
| Effects Loop & Bypass Options | Fully Buffered Series FX Loop |
| Global Output Level Control | n/a |
| Global Solo Level Control & Bypassable Options | n/a |
| True-Bypass Options | n/a |
| Tuner Output | n/a |
| External Switching Jack Options and/or Midi | External Switching Jack for Reverb |
| Speaker Outputs | One 8 Ohm and Two 4 Ohm |
| Cabinet Simulation – Direct Live/Recording Output | n/a |
| Headphone Output | n/a |
| Slave Output | n/a |
Accessories
Footswitch Included – 1 Button Footswitch (Ch. 1/2)
Slip Cover Included – Fitted Slip Cover
Cabinet Features |
|
|---|---|
| Cabinet Material | Marine Grade, Baltic Birch |
| Standard Finish Options (no extra cost) | Choice of Black Taurus or Black Bronco Vinyl with choice of Cream & Black Weave or Black Jute Grille |
| Custom Finish Options | See Custom Finish Gallery |
| Speaker(s) & Impedance | 1 – 8 Ohm Mesa Fillmore 75 / Total Load = 8 Ohms |
| Casters | n/a |
Weight And Dimensions |
|
|---|---|
| Weight | 41 Lbs. |
| Height | 17″ |
| Width | 19″ |
| Depth | 11″ |
